Formula 1 has been a staple in sports broadcasting internationally, exciting fans worldwide for the better part of a century. In many ways, it has represented the forefront of getting the fans involved from every perspective possible. From the track side to the cars themselves, viewers have an increasing number of options. Until as recently as 2017, though, a combination of strict media protocols and underdeveloped technologies hamstrung F1's growth. The media restrictions were lifted following a change in ownership, and the floodgates opened as teams implemented new AV technologies to bring the fans even closer to the track. Global awareness of F1 grew exponentially and coupled with the breakout success of Netflix's Drive to Survive series, a tidal wave of new audiences arrived.

Among these key AV innovations is the implementation of the Driver's Eye, a literal eye-level perspective that allows fans to put themselves right inside the helmets of their favorite drivers.

Yuki Tsunoda, running a lap around the Bahrain International Circuit

Developed by Racing Force Group, the Driver's Eye is a 9mm x 9mm-sized camera fitted to the driver's helmet padding. To successfully implement the Driver's Eye, a variety of technological and situational hurdles had to be addressed. First and foremost, the Driver's Eye had to operate within the safety standards set out for drivers, ensuring that the camera did not come in contact with drivers or obstruct their view. In addition, the camera couldn't pose a risk in a crash scenario, requiring rigorous testing in the process.

Data streaming and broadcasting posed their own challenges. To send back a high-quality signal for global broadcasting, the helmet needed to connect to the car's electronics suite via a thin cable. Each car had to conserve data resources, accommodating aspects such as performance feedback across components. This means that F1's broadcast team must decide which cameras are streamed from which cars, as well as how many active cameras can be broadcast at once. “We’ve only got so much bandwidth off the car,” said Dean Locke, F1’s director of broadcast and media, while speaking with The Race.

Naturally, the bandwidth limits also mean that camera operators must be judicious with the selected cameras, focusing on expected (or unexpected) battles for each position as race conditions change. The Driver's Eye is a narrow, focused field of view and thus omits wider situational awareness from the audience's perspective. As a result, the camera truly shines when drivers are pitted against each other in one-on-one scenarios, such as overtaking another car or defending through a chicane.

The result is an incredibly immersive experience for fans that captures the blistering pace and skilled maneuvering endemic to Formula 1. Watching a lap through the Driver's Eye, it's no surprise as to why F1 represents the pinnacle of racing for many, as drivers react with blinding speed and surgical precision throughout the race. The resounding success of the little camera has spread to other racing leagues, and with the potential it shows, who knows where we may see it next?
