Here are the key considerations for designing a robust and future ready AV system for command and control centres:

• System Reliability

Control rooms operate 24/7, which demands reliable AV systems to prevent downtime. Systems must be designed with resilience in mind, incorporating features such as redundant power supplies, hot swappable components, and modular designs. This ensures that critical operations can continue without disruption, even during maintenance or unexpected failures.

• Scalability and Flexibility

A well designed control room should be adaptable to future growth and technological advancements. Modular systems allow for easy scalability, enabling the addition of new devices or functionalities without needing major system overhauls. Flexible systems support both local and remote connectivity, providing flexibility for various control room layouts and configurations.

• Signal Distribution and Switching

Efficient distribution and seamless switching of audio, video, and control signals are vital. The choice between twisted pair, fiber, or IP based systems depends on the room’s size, security requirements, and distance. Fiber optic solutions provide secure, long distance signal transmission without degradation, making them ideal for sensitive environments.

• Low Latency and High Quality Video

In command centres, realtime video monitoring and analysis are essential. Solutions like Extron's NAV series provide ultralow latency and high-quality 4K video transmission over IP, ensuring operators receive clear and timely visual information. This is particularly important for video walls and multi display setups.

• UserFriendly Control Interfaces

To improve situational awareness and decision making, operators need intuitive control over the AV system. Touch panels with custom user interfaces allow easy control of video wall layouts, audio settings, and signal routing. Systems should also allow seamless switching between different sources, ensuring that critical information is readily available without delays.

• Security

Control and command centres handle sensitive data, requiring secure AV systems that protect against unauthorized access and interference. Secure signal routing, network isolation, and encrypted communications are essential to maintain confidentiality. Products with government grade certifications should be considered for high security environments.

• MultiSource and MultiWindow Display

In modern control rooms, operators often need to view multiple data sources simultaneously. A multi window processor allows operators to display and arrange various sources on a video wall, providing a comprehensive view of all relevant information. The ability to zoom in on specific content or rearrange layouts on the fly enhances operational efficiency.

• Integration with Other Systems

Command centres often integrate AV systems with building management, security systems, and communication platforms. A seamless integration ensures that operators can control lighting, alarms, and other critical infrastructure from the same interface they use for AV controls, improving workflow efficiency.

• Large LED Video Wall for Real-time Monitoring

A central LED video wall serves as the focal point for operators, displaying critical information from various sources such as CCTV feeds, data dashboards, and emergency alerts. Key features to consider when designing the video wall include:

 High-resolution Display: To ensure clarity, especially for detailed visual information such as maps and data, opt for 4K or higher resolution displays.

 MultiWindow Capability: Multiwindow processors allow for simultaneous display of multiple sources in customizable layouts, enabling operators to monitor several data points at once.

 Low Latency: The video wall must deliver real time information with minimal latency to support quick decision making.

 Flexible Source Management: Operators should be able to quickly switch between different sources or reconfigure layouts based on the situation using a touch panel interface.

• Operator and Supervisor Workstations

Operators and supervisors are the core users in a command center, requiring a setup that allows them to control and monitor multiple systems:

 MultiScreen Setups: Each workstation should be equipped with multiple high resolution screens, allowing operators to monitor several applications (e.g., traffic control, CCTV, SCADA systems) simultaneously.

 USB KVM Switching: Extron’s USB switchers enable operators to control multiple computers or systems using a single keyboard and mouse, improving workflow efficiency.

 Instant Switching: The ability to instantly switch between sources and workstations without signal interruption or glitches is critical for maintaining situational awareness.

 Supervisor Workstations: Supervisors may require additional oversight capabilities, with access to data from multiple operators, providing them with an overview of ongoing operations and allowing them to intervene when necessary.

• Local Intercom Communications

Clear, reliable communication is vital in a control room for coordinating between operators, supervisors, and external teams:

 Integrated Intercom System: Local intercom systems should enable easy communication between operator workstations, supervisors, and remote locations. Systems like Dante enabled digital audio processors facilitate seamless communication between different areas of the command center.

 HandsFree Operation: Intercom systems should allow hands-free or voice activated functionality to ensure operators can communicate while continuing their work without distractions.

 Audio Quality: High-quality audio ensures clear communication during emergencies, and integration with other AV systems allows audio announcements to be broadcast through the control room’s speaker system.

• Crisis Management Meeting Room

A dedicated crisis management meeting room allows decision makers to gather and respond to critical events. Integrating AV systems into this room is essential to ensure that crisis management teams have access to the same data and tools as operators in the control center:

 Video Wall and Display Solutions: The meeting room should have a large display or video wall capable of mirroring the main control room's information. This ensures decision makers are seeing the same data in real-time.

 Integrated Videoconferencing: The room should support videoconferencing, allowing external teams or stakeholders to join the discussions.

 Annotation and Collaboration Tools: Touchscreens with annotation capabilities can enhance collaboration by allowing team members to highlight key data or make real-time decisions on displayed content.

 AV and Environmental Control: A single touch panel should provide easy control over AV settings, lighting, and environmental factors like blinds or HVAC to create a suitable meeting environment during emergencies.

• System Reliability and Security

Given the critical nature of command centers, system uptime and security are non-negotiable:

 Redundant Systems: Ensure that power supplies, data connections, and AV components have redundancy to prevent failures. Hot swappable components allow for quick repairs without system downtime.

 Secure AV Transmission: For command centers handling sensitive or classified information, AV systems must ensure data security. Extron’s fiber optic solutions, such as the FOX3 series, provide secure transmission of video, audio, and control signals over long distances.

 Access Control: Systems should incorporate access controls such as Common Access Card (CAC) readers to ensure that only authorized personnel can control specific parts of the AV system or access sensitive information.

• Integration and Flexibility

Control and command centers often integrate AV systems with other essential technologies, such as building management systems, alarm systems, or emergency response protocols:

 Seamless Integration: AV systems must integrate seamlessly with third-party systems such as CCTV, alarm systems, or even emergency broadcast systems. This allows operators to control everything from a central interface.

 Futureproofing: Modular designs ensure that the AV system can easily adapt to future needs without requiring costly upgrades or system replacements.

 Conclusion

The success of a control and command centre hinges on the effectiveness of its AV system. By focusing on reliability, scalability, low latency, security, and ease of use, designers can ensure that the system meets the demanding needs of these mission critical environments. Whether monitoring traffic, managing energy production, or coordinating emergency responses, a well-designed AV system is central to ensuring operational excellence.
